Extra Load LCD Touch Screen Thermostat (Floor & Air Sensing Thermostat) 30 Amps

Programmable 30A Heating Thermostat +  LCD Touch Screen For Underfloor Room

Suitable for larger rooms

Accomodates up 48sqm mats for 150w power and up to 36sqm mats for 200w power

Easy to Install! Easy to Control!

Description:

This Weekly Programmable Heating Thermostat with Touch Screen for underfloor heating system can loop on every week, every day. The application is heating equipment: Water heating system or electric heating or actuator control.

Features:

- Touch Screen,Easy operation and utility.
- Large LCD display with Blue Backlight / White Backlight
- Kinds of periods of time modes. 5+2 / 6+1 / 7days.
- Setting daily 6 periods of time and the setting temperature.
- High reliability and powerful anti-jamming.
- The application is heating equipment: Water heating system or electric heating or actuator control.
- The clock continues when power fail and it won’t affect the period of time settings.
- Mini size junction box and suitable for the entire world.
- Come With 3M Extra sensor label.

- 1 year warranty

Technical Data:

- Power Supply: 60-230VAC ±10% 50/60 Hz
- Maximum switch power: 7200W.
- Maximum switch rating of 30A
- Internal sensor setting range: 5 - 35°C (programmable)
- Internal sensor measurement range: 0 - 40°C
- External sensor measurement range: 0 - 90°C
- Display Type: touch LCD screen, display area size: 60 x 45 mm
- Inside Sensor: NTC B=3380 10k @25degrees Celsius
- Extra Sensor: Length=3M NTC B=3380 10k @25degrees Celsius
- Setting Unit: 0.5°C / step
- Indication Accuracy: 0.1°C
- Certification: CE
- Inner Box Size : 100 x 100 x 60 mm

Package Included:

1 X Thermostat with backlight.
1 X 3m sensor cable.
2 X Mounting screws.
1 X User Manual.
